GC gludas kasešu naglas 2,87x65mm

pieskarties attēlam, lai pietuvinātu

Apraksts

2,87mm smooth stripnail, bright basic, Sencoted

Lasīt vairāk Lasīt mazāk

Izmantošana

Ierāmēšana, Paletes un redeļu kastes, Grīdas apakšklāji, Kopnes

Lasīt vairāk Lasīt mazāk

Saskaņotais standarts EN 14592:2008+A1:2012

Pieprasīt informāciju

Specifikācijas

Identifikācija

Preces numurs: GC55APBKR
GTIN: 8715274028552

Tehniskās specifikācijas

Stiprinājumu leņķis: 34 °
Savienošanas veids: Savilkts ar papīru
Vada materiāls: Standarta stiepes oglekļa tērauds

Stiprinājuma specifikācija

Apdare: Spilgta pamata standarta stiepe
Pārklājums: Pārklāts
Pielietojuma vide: Iekštelpās
Naglu veids: CH slokšņu naglas
Naglu galvu veids: Galva ar klipsi
Naglu kāta veids: Līdzens kāts
Punkta veids: Dimants
Punkta leņķis: 40 °
Vinies skersmuo: 2.87 mm
Stiprinājumu daudzums uz sloksnes/spoles: 29 - 31
Naglu garums: 65.0 mm

CE specifikācija

Raksturīgā uzgaļa izvilkšana caur parametru: 27.12 N/mm²
CE stiprinājuma veids: Apaļa šķērsgriezuma vienkārša kāta nagla
DOP No: GC55APBKR
Pakalpojuma klase: 1
Pārklājuma veids: Pārklājuma 3. veids
Pārklājuma garums: 41.0 mm
Uzgaļa šķērsgriezuma laukums: 30.0 mm
Raksturīgais atdeves moments: 3054.0 Nmm
Raksturīgā stiepes izturība: 695.0 N/mm²
Saskaņotais standarts: EN 14592:2008+A1:2012
Raksturīgā izņemšanas parametra: 2.45 N/mm²

Netehniskas specifikācijas

Iepakojuma daudzums: 2000

Loģistikas specifikācija

Neto svars: 6.73 kg

Saistītie instrumenti

Lejupielādes

GC55APBKR_lv_CommercialProductSheet_1.7_1752289339979 PDF 1 Mb
DOP VS-CPR-201305-S026 PDF 198 Kb
GC55APBKR_lv_DeclarationOfPerformanceDoP_1.0eu_1749141029233 PDF 63 Kb
